ICON 2022-2024 Toyota Tundra 6" Suspension System with Tubular Upper Control Arms

ICON is proud to introduce a range of 6-inch Performance Suspension System "Stage" kits for 2022+ Toyota Tundra. All feature ICON's high clearance 4-inch drop front crossmember kit including a differential skid plate and ductile iron steering knuckles. The crossmember and knuckles drop the front differential 4 inches to preserve CV-joint operating angles, achieving maximum travel while being safe on components and providing great handling characteristics both on- and off-road.

ICON is excited and honored to win SEMA's Best New Off-Road/4-Wheel-Drive Product for 2024, for the new 6" Performance Suspension Systems for 2022-23 Toyota Tundra!

From $6,133.20

Only %1 left

SKU

IVD-23TT6SST_PARENT

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

ICON have pre-configured nine Stages of suspension systems to meet just about any level of performance expectations and budget. Spacer-based Stage 1 retains the stock front coilovers and rear springs to economically fit up to 37" tires. At the other end of the spectrum ICON's fully loaded Stage 9 features a full complement of tubular control arms along with ICON 2.5 VS Coilovers and Shocks featuring cutting-edge CDEV electronic performance technology. Every Stage of ICON's 6-Inch Tundra Systems includes all of the necessary drop brackets, spacers or mounts needed to allow bind-free movement of both the front and rear suspension to coax maximum performance out of every component in the kit.

Part #	Description
IVD-K53271	ICON 2022-2024 Toyota Tundra 6" Stage 1 Suspension System NO UCA
IVD-K53272T	ICON 2022-2024 Toyota Tundra 6" Stage 2 Suspension System Tubular Upper Control Arms
IVD-K53273T	ICON 2022-2024 Toyota Tundra 6" Stage 3 Suspension System Tubular Upper Control Arms
IVD-K53274T	ICON 2022-2024 Toyota Tundra 6" Stage 4 Suspension System Tubular Upper Control Arms
IVD-K53275T	ICON 2022-2024 Toyota Tundra 6" Stage 5 Suspension System Tubular Upper Control Arms
IVD-K53276T	ICON 2022-2024 Toyota Tundra 6" Stage 6 Suspension System Tubular Upper Control Arms
IVD-K53276TD	ICON 2022-2024 Tundra 6" Stage 6 Suspension System Tubular Upper Control Arms, CDXS Shocks
IVD-K53277T	ICON 2022-2024 Toyota Tundra 6" Stage 7 Suspension System Tubular Upper Control Arms
IVD-K53277TD	ICON 2022-2024 Tundra 6" Stage 7 Suspension System Tubular Upper Control Arms, CDXS Shocks
IVD-K53278T	ICON 2022-2024 Toyota Tundra 6" Stage 8 Suspension System Tubular Upper Control Arms
IVD-K53279T	ICON 2022-2024 Toyota Tundra 6" Stage 9 Suspension System Tubular Upper Control Arms

Box Kits Include (Applies to all stages):

IVD-51010 2020-2024 TUNDRA FRONT BOX KIT 1

Front Crossmember
Rear Crossmember

IVD-51011 2020-2024 TUNDRA FRONT BOX KIT 2

Sway Bar Drop
Brake Line Brackets
Outer Tie Rods
Bump Extensions

IVD-51012 2020-2024 TUNDRA REAR BOX KIT

Brake Line Brackets
Track Bar Bracket
Sway Bar Link Mounts
Foam Axle Pads

IVD-K53271T - Stage 1

Features:

Optimized design to fit 37" tires with full articulation (larger tires may fit but fender trimming and modifications will be required)
Maintains factory track width
Front coilover spacer kit with heavy duty steel construction
Provides 6" front suspension lift with only 4" of crossmember drop
Single piece high-strength ductile iron steering knuckles
Hight clearance front crossmembers and front skid plate, CNC Laser Cut and brake-formed from 1/4-inch steel plate
Included sway bar drop brackets reduce bind in OE sway bar links
Front and rear heavy-duty bump stop brackets
High angle outer tie-roads feature durable, metal on metal greaseable tie rod ends
2.0 Aluminum Series rear shocks to improve rear suspension performance
Rear coil spring spacer kit to provide lift while retaining factory rear coil springs
Improved rear sway bar links and mounts, and rear track bar bracket to reduce bind in the rear suspension

Includes:

IVD-51010 2020-2024 TUNDRA FRONT BOX KIT 1
IVD-51011 2020-2024 TUNDRA FRONT BOX KIT 2
IVD-51012 2020-2024 TUNDRA REAR BOX KIT
IVD-51014 2020-2024 TUNDRA FRONT KNUCKLE KIT
IVD-51015 2020-2024 TUNDRA / 23 SEQUOIA 6" COILOVER SPACER KIT
IVD-51016 2020-2024 TUNDRA REAR COIL SPACER KIT
IVD-51017 2020-2024 TUNDRA FRONT SKID PLATE
IVD-56517 2020-2024 TUNDRA 6" REAR 2.0 VS IR (2)

IVD-K53272T Stage 2

Features:

2.5 Series front coilovers with remote reservoirs for superior damping and vehicle control
System allows for up to 40% increase in front wheel travel over stock without overstressing OE components
Optimized design to fit 37" tires with full articulation (larger tires may fit but fender trimming and modifications will be required)
Maintains factory track width
Optimized suspension geometry nearly eliminates the bump steer found in stock Tundras
Adjustable front ride heights from 5-6" of front lift over stock (up to 6" of lift with only 4" of crossmember drop)
Tubular aluminum UCAs with Delta Joint Pro for added strength, durability, and caster correction
Patented Delta Joint Pro (U.S. Pat. 10,731,700) provides improved durability and serviceability with 90 degrees of total articulation
Single piece high-strength ductile iron steering knuckles
Hight clearance front crossmembers and front skid plate, CNC Laser Cut and brake-formed from 1/4-inch steel plate
Included sway bar drop brackets reduce bind in OE sway bar links
Front and rear heavy-duty bump stop brackets
High angle outer tie-roads feature durable, metal on metal greaseable tie rod ends
2.0 Aluminum Series rear shocks provide balanced tune with the front coilovers
Rear coil spring spacer kit to provide lift while retaining factory rear coil springs
Improved rear sway bar links and mounts, and rear track bar bracket to reduce bind in the rear suspension

Includes:

IVD-51010 2020-2024 TUNDRA FRONT BOX KIT 1
IVD-51011 2020-2024 TUNDRA FRONT BOX KIT 2
IVD-51012 2020-2024 TUNDRA REAR BOX KIT
IVD-51014 2020-2024 TUNDRA FRONT KNUCKLE KIT
IVD-58672 2020-2024 TUNDRA 2.5 VS IR 6" COILOVER KIT
IVD-51016 2020-2024 TUNDRA REAR COIL SPACER KIT
IVD-51017 2020-2024 TUNDRA FRONT SKID PLATE
IVD-58461DJ 2020-2024 TUNDRA/23 SEQUOIA TUBULAR UCA DJ PRO KIT
IVD-56517 2020-2024 TUNDRA 6" REAR 2.0 VS IR (2)

IVD-K53273T - Stage 3

Features:

2.5 Series front coilovers with remote reservoirs for superior damping and vehicle control along with improved shock cooling
System allows for up to 40% increase in front wheel travel over stock without overstressing OE components
Optimized design to fit 37" tires with full articulation (larger tires may fit but fender trimming and modifications will be required)
Maintains factory track width
Optimized suspension geometry nearly eliminates the bump steer found in stock Tundras
Adjustable front ride heights from 5-6" of front lift over stock (up to 6" of lift with only 4" of crossmember drop)
Tubular aluminum UCAs with Delta Joint Pro for added strength, durability, and caster correction
Patented Delta Joint Pro (U.S. Pat. 10,731,700) provides improved durability and serviceability with 90 degrees of total articulation
Single piece high-strength ductile iron steering knuckles
Hight clearance front crossmembers and front skid plate, CNC Laser Cut and brake-formed from 1/4-inch steel plate
Included sway bar drop brackets reduce bind in OE sway bar links
Front and rear heavy-duty bump stop brackets
High angle outer tie-roads feature durable, metal on metal greaseable tie rod ends
2.0 Aluminum Series rear shocks with remote reservoirs provide balanced tune with the front coilovers and increased fluid volume for better heat dissipation
ICON engineered custom triple rate rear coil springs provide progressive spring rates for a comfortable ride on-road as well as stability and control during aggressive off-road driving
Improved rear sway bar links and mounts, and rear track bar bracket to reduce bind in the rear suspension

Includes:

IVD-51010 2020-2024 TUNDRA FRONT BOX KIT 1
IVD-51011 2020-2024 TUNDRA FRONT BOX KIT 2
IVD-51012 2020-2024 TUNDRA REAR BOX KIT
IVD-51014 2020-2024 TUNDRA FRONT KNUCKLE KIT
IVD-58771 2020-2024 TUNDRA 2.5 VS RR 6" COILOVER KIT
IVD-51016 2020-2024 TUNDRA REAR COIL SPACER KIT
IVD-58461DJ 2020-2024 TUNDRA/23 SEQUOIA TUBULAR UCA DJ PRO KIT
IVD-51017 2020-2024 TUNDRA FRONT SKID PLATE
IVD-56517R 2020-2024 TUNDRA 6" REAR 2.0 VS RR (2)

IVD-K53274T - Stage 4

Features:

2.5 Series front coilovers and rear shocks with remote reservoirs for superior damping and vehicle control along with improved shock cooling
System allows for up to 40% increase in front wheel travel over stock without overstressing OE components
Optimized design to fit 37" tires with full articulation (larger tires may fit but fender trimming and modifications will be required)
Maintains factory track width
Optimized suspension geometry nearly eliminates the bump steer found in stock Tundras
Adjustable front ride heights from 5-6" of front lift over stock (up to 6" of lift with only 4" of crossmember drop)
Tubular aluminum UCAs with Delta Joint Pro for added strength, durability, and caster correction
Patented Delta Joint Pro (U.S. Pat. 10,731,700) provides improved durability and serviceability with 90 degrees of total articulation
Single piece high-strength ductile iron steering knuckles
Hight clearance front crossmembers and front skid plate, CNC Laser Cut and brake-formed from 1/4-inch steel plate
Included sway bar drop brackets reduce bind in OE sway bar links
Front and rear heavy-duty bump stop brackets
High angle outer tie-roads feature durable, metal on metal greaseable tie rod ends
ICON engineered custom triple rate rear coil springs provide progressive spring rates for a comfortable ride on-road as well as stability and control during aggressive off-road driving
Improved rear sway bar links and mounts, and rear track bar bracket to reduce bind in the rear suspension

Includes:

IVD-51010 2020-2024 TUNDRA FRONT BOX KIT 1
IVD-51011 2020-2024 TUNDRA FRONT BOX KIT 2
IVD-51012 2020-2024 TUNDRA REAR BOX KIT
IVD-51014 2020-2024 TUNDRA FRONT KNUCKLE KIT
IVD-58771 2020-2024 TUNDRA 2.5 VS RR 6" COILOVER KIT
IVD-51013 2020-2024 TUNDRA REAR 3.5 COIL SPRING KIT
IVD-58461DJ 2020-2024 TUNDRA/23 SEQUOIA TUBULAR UCA DJ PRO KIT
IVD-51017 2020-2024 TUNDRA FRONT SKID PLATE
IVD-57841P 2020-2024 TUNDRA 6" REAR 2.5 VS RR PAIR

IVD-K53275T - Stage 5

Features:

2.5 Series front coilovers and rear shocks with remote reservoirs for superior damping and vehicle control along with improved shock cooling
System allows for up to 40% increase in front wheel travel over stock without overstressing OE components
Optimized design to fit 37" tires with full articulation (larger tires may fit but fender trimming and modifications will be required)
Maintains factory track width
Optimized suspension geometry nearly eliminates the bump steer found in stock Tundras
Adjustable front ride heights from 5-6" of front lift over stock (up to 6" of lift with only 4" of crossmember drop)
Tubular aluminum UCAs with Delta Joint Pro for added strength, durability, and caster correction
Patented Delta Joint Pro (U.S. Pat. 10,731,700) provides improved durability and serviceability with 90 degrees of total articulation
Single piece high-strength ductile iron steering knuckles
Hight clearance front crossmembers and front skid plate, CNC Laser Cut and brake-formed from 1/4-inch steel plate
Included sway bar drop brackets reduce bind in OE sway bar links
Front and rear heavy-duty bump stop brackets
High angle outer tie-roads feature durable, metal on metal greaseable tie rod ends
ICON engineered custom triple rate rear coil springs provide progressive spring rates for a comfortable ride on-road as well as stability and control during aggressive off-road driving
High clearance tubular rear lower links feature FK Rod Ends to improve rear end articulation and allow on-vehicle adjustment for different ride heights and pinion angles using ICON's double adjuster system
Improved rear sway bar links and mounts, and rear track bar bracket to reduce bind in the rear suspension

Includes:

IVD-51010 2020-2024 TUNDRA FRONT BOX KIT 1
IVD-51011 2020-2024 TUNDRA FRONT BOX KIT 2
IVD-51012 2020-2024 TUNDRA REAR BOX KIT
IVD-51014 2020-2024 TUNDRA FRONT KNUCKLE KIT
IVD-58771 2020-2024 TUNDRA 2.5 VS RR 6" COILOVER KIT
IVD-51013 2020-2024 TUNDRA REAR 3.5 COIL SPRING KIT
IVD-58461DJ 2020-2024 TUNDRA/23 SEQUOIA TUBULAR UCA DJ PRO KIT
IVD-54002T 2020-2024 TUNDRA/23 SEQUOIA TUBULAR REAR LOWER LINK KIT
IVD-51017 2020-2024 TUNDRA FRONT SKID PLATE
IVD-57841P 2020-2024 TUNDRA 6" REAR 2.5 VS RR PAIR

IVD-K53276T - Stage 6

Features:

2.5 Series front coilovers and rear shocks with remote reservoirs for superior damping and vehicle control along with improved shock cooling
System allows for up to 40% increase in front wheel travel over stock without overstressing OE components
Optimized design to fit 37" tires with full articulation (larger tires may fit but fender trimming and modifications will be required)
Maintains factory track width
Optimized suspension geometry nearly eliminates the bump steer found in stock Tundras
Adjustable front ride heights from 5-6" of front lift over stock (up to 6" of lift with only 4" of crossmember drop)
Tubular aluminum UCAs with Delta Joint Pro for added strength, durability, and caster correction
Patented Delta Joint Pro (U.S. Pat. 10,731,700) provides improved durability and serviceability with 90 degrees of total articulation
Single piece high-strength ductile iron steering knuckles
Hight clearance front crossmembers and front skid plate, CNC Laser Cut and brake-formed from 1/4-inch steel plate
Included sway bar drop brackets reduce bind in OE sway bar links
Front and rear heavy-duty bump stop brackets
High angle outer tie-roads feature durable, metal on metal greaseable tie rod ends
ICON engineered custom triple rate rear coil springs provide progressive spring rates for a comfortable ride on-road as well as stability and control during aggressive off-road driving
Improved rear sway bar links and mounts, and rear track bar bracket to reduce bind in the rear suspension

Includes:

IVD-51010 2020-2024 TUNDRA FRONT BOX KIT 1
IVD-51011 2020-2024 TUNDRA FRONT BOX KIT 2
IVD-51012 2020-2024 TUNDRA REAR BOX KIT
IVD-51014 2020-2024 TUNDRA FRONT KNUCKLE KIT
IVD-58771C 2020-2024 TUNDRA 2.5 VS RR CDCV 6" COILOVER KIT
IVD-51013 2020-2024 TUNDRA REAR 3.5 COIL SPRING KIT
IVD-58461DJ 2020-2024 TUNDRA/23 SEQUOIA TUBULAR UCA DJ PRO KIT
IVD-51017 2020-2024 TUNDRA FRONT SKID PLATE
IVD-57841CP 2020-2024 TUNDRA 6" REAR 2.5 VS CDCV RR PAIR

IVD-K53276TD - Stage 6 with CDXS Coilovers and Shocks

Extra-Tall suspension systems are made possible for 2022-24 Toyota Tacoma with ICON's proprietary ductile iron steering knuckles and fabricated drop crossmembers for the front, along with sway bar and suspension link drop brackets for the rear. These systems feature the performance and tunability of ICON's 2.5 VS Coilovers and Shocks with CDXS technology.

6" Stage 6 provides CDXS Coilovers and Shocks, Delta Joint Pro UCAs, 3.5" Triple Rate Rear Coil Springs and all of the necessary steering knuckles, crossmembers and drop brackets to yield a high performing 6" suspension system without steering or CV bind.

IVD-K53277T - Stage 7

Features:

ICON's Compression Damping Electronic Valves (CDCV) provide easy manual adjustment of compression damping for each shock with 10 settings from soft to firm
System allows for up to 40% increase in front wheel travel over stock without overstressing OE components
Optimized design to fit 37" tires with full articulation (larger tires may fit but fender trimming and modifications will be required)
Maintains factory track width
Optimized suspension geometry nearly eliminates the bump steer found in stock Tundras
2.5 Series front coilovers and rear shocks with remote reservoirs for superior damping and vehicle control along with improved shock cooling
Adjustable front ride heights from 5-6" of front lift over stock (up to 6" of lift with only 4" of crossmember drop)
Tubular aluminum UCAs with Delta Joint Pro for added strength, durability, and caster correction
Patented Delta Joint Pro (U.S. Pat. 10,731,700) provides improved durability and serviceability with 90 degrees of total articulation
Single piece high-strength ductile iron steering knuckles
Hight clearance front crossmembers and front skid plate, CNC Laser Cut and brake-formed from 1/4-inch steel plate
Included sway bar drop brackets reduce bind in OE sway bar links
Front and rear heavy-duty bump stop brackets
High angle outer tie-roads feature durable, metal on metal greaseable tie rod ends
ICON engineered custom triple rate rear coil springs provide progressive spring rates for a comfortable ride on-road as well as stability and control during aggressive off-road driving
Tubular rear upper and high clearance lower links feature FK Rod Ends to improve rear end articulation and allow on-vehicle adjustment for different ride heights and pinion angles using ICON's double adjuster system
On-vehicle adjustable billet rear track bar properly centers rear axle while also improve rear suspension performance
Improved rear sway bar links and mounts, and rear track bar bracket to reduce bind in the rear suspension

Includes:

IVD-51010 2020-2024 TUNDRA FRONT BOX KIT 1
IVD-51011 2020-2024 TUNDRA FRONT BOX KIT 2
IVD-51012 2020-2024 TUNDRA REAR BOX KIT
IVD-51014 2020-2024 TUNDRA FRONT KNUCKLE KIT
IVD-58771C 2020-2024 TUNDRA 2.5 VS RR CDCV 6" COILOVER KIT
IVD-51013 2020-2024 TUNDRA REAR 3.5 COIL SPRING KIT
IVD-58461DJ 2020-2024 TUNDRA/23 SEQUOIA TUBULAR UCA DJ PRO KIT
IVD-51017 2020-2024 TUNDRA FRONT SKID PLATE
IVD-57841CP 2020-2024 TUNDRA 6" REAR 2.5 VS CDCV RR PAIR
IVD-54002T 2020-2024 TUNDRA/23 SEQUOIA TUBULAR REAR LOWER LINK KIT
IVD-54102T 2020-2024 TUNDRA/23 SEQUOIA TUBULAR REAR UPPER LINK KIT
IVD-54202 2020-2024 TUNDRA/23 SEQUOIA BILLET REAR ADJ TRACK BAR KIT

IVD-K53277TD - Stage 7 with CDXS Coilovers and Shocks

6" Stage 7 adds Billet or Tubular Rear Suspension Links as well as ICON's Billet Adjustable Rear Track Bar to fine tune rear suspension geometry and alignment.

IVD-K53278T - Stage 8

Features:

ICON's Compression Damping Electronic Valve (CDEV) technology allows for in vehicle adjustment of compression damping settings and active adjustment via IIC
ICON Intelligent Control (IIC) uses onboard sensors to monitor G-forces and movement of vehicle chassis along with user defined settings to actively make on-the-fly, near instantaneous compression damping adjustments on CDEV-equipped shocks
System allows for up to 40% increase in front wheel travel over stock without overstressing OE components
Optimized design to fit 37" tires with full articulation (larger tires may fit but fender trimming and modifications will be required)
Maintains factory track width
Optimized suspension geometry nearly eliminates the bump steer found in stock Tundras
2.5 Series front coilovers and rear shocks with remote reservoirs for superior damping and vehicle control along with improved shock cooling
Adjustable front ride heights from 5-6" of front lift over stock (up to 6" of lift with only 4" of crossmember drop)
Tubular aluminum UCAs with Delta Joint Pro for added strength, durability, and caster correction
Patented Delta Joint Pro (U.S. Pat. 10,731,700) provides improved durability and serviceability with 90 degrees of total articulation
Single piece high-strength ductile iron steering knuckles
Hight clearance front crossmembers and front skid plate, CNC Laser Cut and brake-formed from 1/4-inch steel plate
Included sway bar drop brackets reduce bind in OE sway bar links
Front and rear heavy-duty bump stop brackets
High angle outer tie-roads feature durable, metal on metal greaseable tie rod ends
ICON engineered custom triple rate rear coil springs provide progressive spring rates for a comfortable ride on-road as well as stability and control during aggressive off-road driving
Improved rear sway bar links and mounts, and rear track bar bracket to reduce bind in the rear suspension

IVD-K53279T - Stage 9

Features:

ICON's Compression Damping Electronic Valve (CDEV) technology allows for in vehicle adjustment of compression damping settings and active adjustment via IIC
ICON Intelligent Control (IIC) uses onboard sensors to monitor G-forces and movement of vehicle chassis along with user defined settings to actively make on-the-fly, near instantaneous compression damping adjustments on CDEV-equipped shocks
System allows for up to 40% increase in front wheel travel over stock without overstressing OE components
Optimized design to fit 37" tires with full articulation (larger tires may fit but fender trimming and modifications will be required)
Maintains factory track width
Optimized suspension geometry nearly eliminates the bump steer found in stock Tundras
2.5 Series front coilovers and rear shocks with remote reservoirs for superior damping and vehicle control along with improved shock cooling
Adjustable front ride heights from 5-6" of front lift over stock (up to 6" of lift with only 4" of crossmember drop)
Tubular aluminum UCAs with Delta Joint Pro for added strength, durability, and caster correction
Patented Delta Joint Pro (U.S. Pat. 10,731,700) provides improved durability and serviceability with 90 degrees of total articulation
Single piece high-strength ductile iron steering knuckles
Hight clearance front crossmembers and front skid plate, CNC Laser Cut and brake-formed from 1/4-inch steel plate
Included sway bar drop brackets reduce bind in OE sway bar links
Front and rear heavy-duty bump stop brackets
High angle outer tie-roads feature durable, metal on metal greaseable tie rod ends
ICON engineered custom triple rate rear coil springs provide progressive spring rates for a comfortable ride on-road as well as stability and control during aggressive off-road driving
Tubular rear upper and high clearance lower links feature FK Rod Ends to improve rear end articulation and allow on-vehicle adjustment for different ride heights and pinion angles using ICON's double adjuster system
On-vehicle adjustable billet rear track bar properly centers rear axle while also improve rear suspension performance
Improved rear sway bar links and mounts, and rear track bar bracket to reduce bind in the rear suspension
